Iron City Supply

Drive Over HD Truck Unloader

Drive Over HD Truck Unloader

$92,400.00 USD
$92,400.00 USD
Sale Sold out

Belly dump your rock, grain, salt, frac sand quickly with our drive over truck unloader.  Everything on this unit is customizable, but standard units as shown are usually in stock.

48” HD End Dump Unloader:  1500 tph @ 100 pcf on 48" Belt

  • 15” Channel Frame
  • 30hp TEFC 3 phase 230/460v motor
  • #6-25 Reducer
  • 16” Lagged Head Pulley, Shaft & Roller Bearings
  • 7” Winged Tail Pulley w/Screw Take-ups
  • 4” x 35 deg Top Rollers on 48” Centers
  • 3 ply 330 PIW belt
  • Set of Four 4'x16' Ramps
  • Drive Over Grates
  • Tail Guard and head and tail pinch guards
  • Primed & Painted

Final price determined by customer specifications

Call or email for price and availability.  814-701-2111

sales@ironcitysupply.com

HD Truck Unloader Demonstration: Watch how this truck unloads salt quickly onto the jump conveyor and into the storage warehouse.

What is a drive over truck unloader?

A drive over truck unloader allows belly dump trucks to unload rock, grain, salt, or frac sand quickly onto a conveyor system for bulk material handling.

How fast can a belly dump truck be unloaded?

Heavy duty drive over truck unloaders can unload material at capacities up to 1500 tons per hour depending on conveyor width and material density.
