Iron City Supply NEW 24x60 Radial Stacker

Price starts at $24,700.00

Email sales@ironcitysupply.com or call 814-233-9974 with your specs and we'll get you a custom quote usually within a day.

Iron City Supply NEW 24x60 Radial Stacker

• 36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
• Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
• Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
• Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
• World Wide #3 Drive, Motor Mount, Belt Guard
• 7.5 hp, TEFC, 1800 RPM, 230/460 volt
• Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
• Pioneer, 5” Returns w/Brackets, 10’ Centers
• Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
• 48” Load Zone w/Skirt Rubber
• Pivot Plate, Tow Hook
• Tail Guard
• Primed & Painted, Tool Steel Gray, Unless Specified Differently

*Shipping is the responsibility of the customer.  If you need a shipping quote, let us know your delivery zip and we'll get you flat bed or step deck rate.

Available Add-Ons & Pricing

• Price w/ Catwalk — $2,880.00
• Power Travel — Add $3,600.00
• Back Stop — Add $330.00
• 3-Ply Belt — Add $350.00
• Belt Scraper — Add $940.00
• Chevron Belting — Add $810.00
• 7.5 HP Motor Starter Panel — Add $2,660.00
• 2 HP Power Travel Reversing Motor Starter — Add $1,695.00
• 12” Load Zone Extensions — Add $325.00
• Grease Lines — Add $475.00

Contact us to add these options or configure a fully customized system for your operation.
