Pit Portable 30x40 Radial Stacker NEW

Price Starts at $20,100.00

Call for a custom quote 814-233-9974 or email sales@ironcitysupply.com

Iron City Supply NEW 30x40 Radial Stacker - Options pricing available upon request

• 24” Deep Truss, 2x2x1/4 Cord Angle,11/2x11/2x3/16 Lattice
• Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
• Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
• Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
• World Wide #3 Drive, Motor Mount, Belt Guard
• 5 hp, TEFC, 1800 RPM, 230/460 volt
• Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
• Pioneer, 5” Returns w/Brackets, 10’ Centers
• Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
• 48” Load Zone w/Skirt Rubber
• Pivot Plate, Tow Hook
• Tail Guard
• Primed & Painted, Tool Steel Gray, Unless Specified Differently

Available Add-Ons & Pricing

• Catwalk — Add $1,920.00
• Power Travel — Add $3,600.00
• Back Stop — Add $330.00
• 3-Ply Belt — Add $300.00
• Chevron V-Cleat Belt — Add $540.00
• Belt Scraper — Add $1,010.00
• 7.5 HP Motor Starter Panel — Add $2,650.00
• 2 HP Power Travel Reversing Motor Starter — Add $1,695.00
• 12” Load Zone Extensions — Add $325.00
• Grease Lines — Add $360.00

Contact us to add these options or configure a fully customized system for your operation.
