Iron City Supply NEW 36x60 Radial Stacker

Iron City Supply NEW 36x60 Radial Stacker

Regular price $19,150.00 Sale

Iron City Supply NEW 30x60 Radial Stacker - options pricing available upon request

  • 36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
  • Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Dual Tires & Rims
  • Lagged head 16” Dia., 2 7/16” Shaft & Ball Bearing
  • Winged Tail, 2 7/16” Shaft & Ball Bearings w/Screw Take-ups
  • World Wide #4 Drive, Motor Mount, Belt Guard
  • 15 hp, TEFC, 1800 RPM, 230/460 volt
  • Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
  • Pioneer, 5” Returns w/Brackets, 10’ Centers
  • Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
  • 48” Load Zone w/Skirt Rubber
  • Pivot Plate, Tow Hook
  • Tail Guard
  • Primed & Painted, Tool Steel Gray, Unless Specified Differently

PRICE………………………………………………………………………....$19,150.00
